Technical Papers and Presentations

Ici vous trouverez les présentations issues des Conférences COMSOL à travers le monde. Réalisées par des utilisateurs de COMSOL Multiphysics, ces présentations explorent tous les domaines actuels d'innovation. Les applications couvrent pratiquement tous les secteurs industriels et impliquent des phénomènes électriques, mécaniques, fluidiques et chimiques. Utilisez la recherche rapide pour trouver les présentations les plus intéressantes dans votre domaine d'intérêt.

Opto-Asic, Photonische Kristalle

Ricklefs, U., Luo, H.
FH Giessen-Friedberg, FB EI

Mit FEMLAB 2.x und 3.1 wurden Voruntersuchungen zu zwei Anwendungen versucht. Im ersten Projekt sollte die Möglichkeit geklärt werden, FEMLAB für die Verhaltenssimulation integrierter ASIC-Photodioden einzusetzen und in der zweiten Anwendung sollten spezielle photonische Kristalle untersucht werden.

Simulating the Generation and Guided Propagation of Terahertz Radiation using COMSOL Multiphysics

Jason A. Deibel
Rice University

Electromagnetic waves within the Teraherz frequency spectrum are common in medical techonolgy applications, such as imaging, spectroscopy and drug detection. In this presentation, we explain how Teraherz Radiation is used in different applications, how to produce Electromagnetic waves in the Teraherz frequency, and how to analyze them. Simulations in COMSOL Multiphysics are included as ...

Complex K-Bands Calculation for Plasmonic Crystal Slabs by Means of Weak Formulation of Helmholtz's Eigenvalue Equation

G. Parisi[1], P. Zilio[1], F. Romanato[1]
[1]University of Padova, Padova, Italy

We present a Finite Element Method (FEM) to calculate the complex valued k(?) dispersion curves of a photonic crystal slab in presence of both dispersive and lossy materials. In particular the method can be exploited to study plasmonic crystal slabs. We adopt Perfectly Matched Layers (PMLs) in order to truncate the open boundaries of the model, including their related anisotropic permittivity and ...

FEM Study of Nano-structured Surface-relief Optical Data Storage

Kalavagunta, A.1, Neifeld, M.A.2
1 Vanderbilt University, Nashville, TN
2 Univerisity of Arizona, Tucson, AZ

We are studying the ability of subresolution optical structures to store data. We begin our study with surface relief structures. Because we are probing features whose sizes are much smaller than the wavelength of the readout light, retrieval of data from these structures requires near-field detection. The dimensions of the glass fill-in and the grooves of the above mentioned structure was ...

Finite Element Modeling of Electromagnetic Scattering for Microwave Breast Cancer Detection

R. Firoozabadi[1], and E.L. Miller[2]
[1]Airvana Inc., Chelmsford, MA, USA
[2]Tufts University, Medford, MA, USA

In this paper, COMSOL Multiphysics software is utilized as a finite element forward solver to obtain the electromagnetic fields at the receiving antennas while the breast is illuminated by one antenna in the array. Geometry consists of coronal slices of the 3-D breast. Simulations are done by a MATLAB code which runs COMSOL finite element solver and collects the data at the receiving antennas at ...

Multiphysics Analysis of Normal Conducting RF Cavities for High Intensity Proton Accelerators

M. Hassan[1], I. Gonin[1], T. Khabiboulline[1], V. Yakovlev[1]
[1]Fermi National Accelerator Laboratory, Batavia, IL, USA

Normal conducting cavities are typically used in the front end of proton accelerators to get the beam accelerated to velocities approximately a few tenths of the speed of light, where superconducting cavities can then be used to accelerate the beam to the speed of light. The warm part of a typical proton accelerator would contain a radio frequency quadrupole (RFQ) and several buncher cavities. ...

Resonances in Tapered Double-Port TEM Waveguides

J. Kaerst
HAWK, Fachhochschule Hildesheim/Holzminden/Göttingen, Germany

In this paper resonances in tapered double-port TEM waveguides are used as benchmark for simulations. FEM simulations with COMSOL Multiphysics® and simulations using generalised telegraphist's equations with MATLAB® are compared to ananalytical method capable of calculating the resonances of higher order modes. It is valid for tapered double-port TEM waveguides with constant ...

Calculations of the FMR Spectrum in 1D Magnonic Crystals

M. Mruczkiewicz[1], M. Krawczyk[1], V.K. Sakharov[2], Yu. V. Khivintsev[2], Yu. A. Filimonov[2], S. A. Nikitov[3]
[1]Nanomaterials Physics Division, Faculty of Physics, Adam Mickiewicz University, Pozna?, Poland
[2]Kotel’nikov Institute of Radio Engineering and Electronics, Russian Academy of Sciences (Saratov Branch), Saratov, Russia; Laboratory “Metamaterials”, Chernyshevsky Saratov State University, Saratov, Russia
[3]Kotel’nikov Institute of Radio Engineering and Electronics, Russian Academy of Sciences, Moscow, Russia; Laboratory “Metamaterials”, Chernyshevsky Saratov State University, Saratov, Russia

FMR spectra of the periodic microstructures (one-dimensional magnonic crystals, 1D MCs) were obtained using COMSOL with use partial differential equation interface. Results of these calculations were successfully compared with an experimental data for Damon-Eshbach (DE) and Backward-Volume (BV) geometries. The presented tool allows to analyze periodic structures with various geometries and ...

S-parameter Sensitivity Analysis of Waveguide Structures with FEMLAB

Li, D., Nikolova, N.K.
Computational Electromagnetics Research Laboratory, Department of Electrical and Computer Engineering, McMaster University, Hamilton, Ontario

For the purpose of accurate and efficient design of a microwave structure, sophisticated optimization techniques are typically used. The optimization process can greatly benefit from the availability not only of the objective function, but also its gradient. Numerical electromagnetic solvers do not provide the gradient information, thus defaulting to the finite-difference approximation at the ...

Simulation of Realistically Shaped Nanoantennas Using COMSOL Multiphysics

C. Moosmann, G. Sigurdsson, K. Dopf, M. D. Wissert, H.-J. Eisler, and U. Lemmer
Light Technology Institute
Karlsruhe Institute of Technology
Karlsruhe, Germany

Nanoantennas – nanometer sized gold structures resonant at optical wavelengths have interesting properties for many applications. For numerical simulations of such structures simplified geometries are usually considered. However the fabricated shapes still differ significantly from perfect geometries and such structures are sensitive to geometrical changes. Here, we investigate how the ...
