La Bibliothèque d'Applications présente des modèles construits avec COMSOL Multiphysics pour la simulation d'une grande variété d'applications, dans les domaines de l'électromagnétisme, de la mécanique des solides, de la mécanique des fluides et de la chimie. Vous pouvez télécharger ces modèles résolus avec leur documentation détaillée, comprenant les instructions de construction pas-à-pas, et vous en servir comme point de départ de votre travail de simulation. Utilisez l'outil de recherche rapide pour trouver les modèles et applications correspondant à votre domaine d'intérêt. Notez que de nombreux exemples présentés ici sont également accessibles via la Bibliothèques d'Applications intégrée au logiciel COMSOL Multiphysics® et disponible à partir du menu Fichier.
This example uses the Granular Flow interface to model the formation of the grain heap and then its subsequent spreading using a cylindrical roller. The roller has a combined rotational and translational motion. The resulting powder bed is then analyzed to determine its quality based on ... En savoir plus
Turbulent flow, Elliptic Blending R-ε interface is used to analyze fully developed turbulent flow in a spanwise rotating channel. Due to the influence of Coriolis force on turbulence, profiles of the flow variables are skewed at moderate rotation rate. The asymmetry between cyclonic ... En savoir plus
This model demonstrates the filtration of grains of three different sizes as they pass through two vibrating sieves of different hole sizes. En savoir plus
This model shows three methods to focalise external irradiation with a convex glass lens made of either: Semitransparent Surface with no reflection. Refractive Interface following the Fresnel's relations. Dielectric Window absorbing ultraviolet and infrared radiations. En savoir plus
At the bottom of an oil well, the pressure and temperature can differ significantly from those at the surface. As the oil mixture flows upward and the pressure decreases, phase changes may occur. At the wellbore inlet, the mixture may already contain both liquid and gas phases. ... En savoir plus
Free-surface calculations in the predefined flow interfaces are currently limited to time-dependent studies when using the built-in boundary conditions. Here, a stationary formulation following Romero et al. [1] is implemented using equation contributions. The attached slides describe ... En savoir plus
This model showcases a nail penetration experiment into a layered battery. It couples the Solid Mechanics, Lithium-Ion Battery, and Heat Transfer interfaces. A nail is punched into a sandwiched battery consisting of two electrodes and a separator. As soon as the nail connects both ... En savoir plus
This model presents a way to compute projected area using the Surface-to-Surface Radiation interface of the Heat Transfer Module. By computing illuminated area from a set of directions on a discretized sphere, it is possible to interpolate the projected area onto any angle of incidence. ... En savoir plus
Coaxial pipes are used in a variety of applications, including geothermal borehole heat exchangers. In this model, cold water is injected through the inner pipe and returns through the annular region between the inner and outer pipes, absorbing heat from the surrounding subsurface. The ... En savoir plus
In electrosurgery, high-power AC current from a probe is driven into tissue in order to cut and coagulate it. The current causes rapid Joule heating near the tip, and as temperatures reach 100°C, water and blood vaporize and the tissue desiccates, enabling cutting or sealing. This ... En savoir plus
