Ici vous trouverez les présentations issues des Conférences COMSOL à travers le monde. Réalisées par des utilisateurs de COMSOL Multiphysics, ces présentations explorent tous les domaines actuels d'innovation. Les applications couvrent pratiquement tous les secteurs industriels et impliquent des phénomènes électriques, mécaniques, fluidiques et chimiques. Utilisez la recherche rapide pour trouver les présentations les plus intéressantes dans votre domaine d'intérêt.

Design and Stress Analysis of a General Aviation Aircraft Wing

G. Atmeh[1], F. Darwish[1], and Z. Hasan[2]
[1]Jordan University of Science and Technology, Irbid, Jordan
[2]Texas A&M University, College Station, TX, USA

The present study focuses on the design and analysis of a single-engine, propeller-driven general aviation airplane. Initial weight estimation based on the initial sketch and the design mission profile is conducted. The estimated weight and other design parameters are used to define the external geometry of the fuselage, wing and tail. Conic lofting is utilized to render a layout of the design ...

Influence of Air Gap Length and Cross-Section on Magnetic Circuit Parameters - new

A. Polit[1], R. Jez[1]
[1]ABB Corporate Research Center, Krakow, Poland

The air gap is one of the most crucial part of magnetic circuits, especially in high-power inductors. It significantly modifies the parameters of magnetic devices by increasing the saturation current, linearizing B-H curve of magnetic circuit and causing a decreasing in the inductance. Therefore the optimal selection of shape and dimensions of the air gap is very important from the design point ...

Study of Effect on Resonance Frequency of Piezoelectric Unimorph Cantilever for Energy Harvesting

G. R. Prakash[1], K. M. V. Swamy[1], S. Huddar[1], B. G. Sheeparamatti[1], Kirankumar B. B.[1]
[1]Basaveshwar Engineering College, Bagalkot, Karnataka, India

The focus of this paper is to study the effect on resonance frequency and power enhancement techniques[1] of piezoelectric MEMS and modeling, design, and optimization of a piezoelectric generator based on a two-layer bending element(Figure 1) using COMSOL Multiphysics. An analytical relation was developed based on the shift in resonance frequency(Figure 2) caused by the addition of a thin film ...

Mie Scattering of Electromagnetic Waves

J. Crompton[1], S. Yushanov[1], K. Koppenhoefer[1]
[1]AltaSim Technologies, Columbus, OH, USA

The Mie solution to the scattering of electromagnetic waves by spherical particles has been examined using COMSOL Multiphysics®. The results assume elastic scattering only and do not include Brillouin or Raman scattering. The nature of the interaction has been considered for materials with three different properties: metallic, magnetic and dielectric. The solutions provide details of the ...

Theory of Proportional Solenoids and Magnetic Force Calculation Using COMSOL Multiphysics

O. Vogel, and J. Ulm
Heilbronn University
Campus Künzelsau
Künzelsau, Germany

Proportional solenoids are well-known and used in a wide range of applications today. This paper is about methods of influencing the characteristic force-stroke-curves of magnetic actuators by means of different pole geometries. The conical design of the stator pole which is mostly used to accomplish proportional solenoids is analyzed by both a simple analytic reluctance model and a FEM model ...

Analysis of Burning Candle

J.S. Crompton, L.T. Gritter, S.Y. Yushanov, and K.C. Koppenhoefer
AltaSim Technologies LLC, Columbus, OH, USA

Analysis of burning candles is extremely complex; combustion produces a highly non-linear temperature profile through the flame in which local temperatures may exceed 1400 °C. Heat transfer includes radiation, conduction and convection components and the low melting point of the candle wax leads to a phase change that allows mass transport via capillary flow prior to combustion in the flame. ...

Fluid Motion Between Rotating Concentric Cylinders Using COMSOL Multiphysics® Software

P. L. Mills [1], K. Barman [1], S. Mothupally [1], A. Sonejee [1],
[1] Texas A&M University - Kingsville, Kingsville, TX, USA

Introduction Fluid flow patterns in research or process-scale equipment where a fluid is contained between concentric rotating cylinders in the absence of bulk axial flow has received notable attention in the field of fluid mechanics. Annular flows occur in many practical applications, such as in the production of oil and gas, fluid viscometers, centrifugally-driven separation processes, ...

Magnetic Levitation System for Take-off and Landing Airplane – Project GABRIEL

K. Falkowski[1], K. Sibilski[1]
[1]Wroclaw University of Technology, Wrocław, Poland

In the paper will be presented the construction of passive magnetic suspension with superconductors. The system of magnetic suspension was designed for GBRIEL project. There is presented numerical test bench of passive magnetic suspension with superconductor. This kind of suspension was selected for generation of magnetic levitation forces in a sledge of take-off and landing system of an ...

Implementation of the Perfectly Matched Layer to Determine the Quality Factor of Axisymmetric Resonators in COMSOL

M.I. Cheema, and A.G. Kirk
McGill University, Montreal, QC, Canada

Due to the inseparability of the wave equation, numerical methods are needed to develop an accurate electromagnetic model for various axisymmetric resonators such as micro-discs and micro-toroids. Our purpose is the implementation of a perfectly matched layer to determine the quality factor of axisymmetric resonators with high accuracy in COMSOL. We treated the perfectly matched layer as an ...

The Design of a Multilayer Planar Transformer for DC/DC Converter with a Resonant Inverter - new

M. Puskarczyk[1], R. Jez [1]
[1]ABB Corporate Research Center, Krakow, Poland

Multilayer planar transformers are widely implemented in power electronic applications. The design process of these elements is complicated due to the complexity of a magnetic circuit and high frequency interactions between windings. Additionally, an analytical approach to the analysis (based on mathematical formulas) can be uncertain. The applied FEM method of the analysis can be a solution to ...

First
Previous
1–10 of 4109
