Fabry-Perot Cavity

This is an example of a Fabry-Perot cavity, the simplest optical resonator structure. It is a classical problem in optics and photonics. Two methods are shown for computing the Q-factor. The losses in this model are purely via radiation away from the resonator.

Plasmonic Wire Grating (Wave Optics)

Surface plasmon-based circuits are being used in applications such as plasmonic chips, light generation, and nanolithography. The Plasmonic Wire Grating Analyzer application computes the coefficients of refraction, specular reflection, and first-order diffraction as functions of the angle of incidence for a plasmonic wire grating on a dielectric substrate. The model describes a unit cell of the ...

Stress-Optical Effects with Generalized Plane Strain

Planar photonic waveguides in silica (SiO2) have great potential for use in wavelength routing applications. The major problem with this type of waveguide is birefringence. Anisotropic refractive indices result in fundamental mode splitting and pulse broadening. The goal is to minimize birefringence effects by adapting materials and manufacturing processes. One source of birefringence is the use ...

Self-Focusing

A Gaussian beam is launched into BK-7 optical glass. The material has an intensity-dependent refractive index. At the center of the beam, the refractive index is the largest. The induced refractive index profile counteracts diffraction and actually focuses the beam. Self-focusing is important in the design of high-power laser systems. The model demonstrates 3D nonlinear wave propagation.

Computing the Scattering of Light from a Rough Surface with a Metal Coating

These examples demonstrate how to compute the total reflection, transmission, and absorption of light when a plane wave, at optical wavelengths, is incident upon a dielectric slab with a thin metal coating. Three examples are included that show: 1. An optically flat slab 2. A slab with a sinusoidal variation in height 3. A slab with random roughness These model files relate to the blog ...

Step-Index Fiber Bend

The first part of the application computes the modes for a straight step index fiber made of silica glass. In the second part, a step index fiber bend with a 3 mm radius of curvature is analyzed with respect to propagating modes and radiation loss. It is shown how to find the power averaged mode radius and how to use this to compute the effective mode index.

Time-Domain Modeling of Dispersive Drude-Lorentz Media (Wave Optics)

This tutorial shows how to solve the full time-dependent wave equation in dispersive media such as plasmas and semiconductors. The 2D TM in-plane wave model solves for the vector potential from the wave equation and for an auxiliary electric polarization density from an ordinary differential equation. The geometry consists of a single dispersive slab with a sub-wavelength slit in it. Periodic ...

Gaussian Beam Incident at the Brewster Angle

This model demonstrates the polarization properties for a Gaussian beam incident at an interface between two media at the Brewster angle. The model shows how to use the Electromagnetic Waves, Beam Envelopes physics interface with a User defined phase specification. Matched Boundary Condition features are used for absorbing waves incident to boundaries at non-normal directions.

Second Harmonic Generation of a Gaussian Beam (Wave Optics)

It is possible to generate harmonics that are multiples of the frequency of laser light by using nonlinear optical materials. This model demonstrates second harmonic generation using transient wave simulation and nonlinear material properties. A YAG (lambda=1.06 micron) laser beam is focused on a nonlinear crystal so that the waist of the beam is inside the crystal.

Multipole Analysis of Electromagnetic Scattering

The multipole expansion is a powerful tool for analyzing electromagnetic waves scattered by small objects. In the expansion, the scattered field is represented as a superposition of the fields created by a finite set of point multipoles. Each point multipole is connected to a unique electric current mode in the object. This connection can be harnessed to design scatterers with prescribed ...
