Electrode-Expansion-Induced Convection in a Stacked Lithium-Ion Battery Cell
Application ID: 148311
The electrodes of a lithium-ion battery are porous and consist of an active solid electrode material, a binder, and pores filled with a liquid electrolyte.
Expansion of the active material due to lithium intercalation changes the volume fraction of electrolyte-filled pores in the electrodes, which in turn induces convection of the electrolyte.
This tutorial demonstrates how to model electrode-expansion–induced electrolyte convection in a lithium-ion battery cell with a stacked configuration.
This model example illustrates applications of this type that would nominally be built using the following products:
however, additional products may be required to completely define and model it. Furthermore, this example may also be defined and modeled using components from the following product combinations:
The combination of COMSOL® products required to model your application depends on several factors and may include boundary conditions, material properties, physics interfaces, and part libraries. Particular functionality may be common to several products. To determine the right combination of products for your modeling needs, review the Grille des Spécifications and make use of a free evaluation license. The COMSOL Sales and Support teams are available for answering any questions you may have regarding this.
