Stress Analysis of an Elliptic Membrane

Model ID: 14377

This is a benchmark model for a plane stress problem. The accuracy of the computed stress concentration is evaluated, and a mesh convergence study is performed for different element types.

Ce modèle a été construit avec les éléments suivants:

Structural Mechanics Module
