La Bibliothèque d'Applications présente des modèles construits avec COMSOL Multiphysics pour la simulation d'une grande variété d'applications, dans les domaines de l'électromagnétisme, de la mécanique des solides, de la mécanique des fluides et de la chimie. Vous pouvez télécharger ces modèles résolus avec leur documentation détaillée, comprenant les instructions de construction pas-à-pas, et vous en servir comme point de départ de votre travail de simulation. Utilisez l'outil de recherche rapide pour trouver les modèles et applications correspondant à votre domaine d'intérêt. Notez que de nombreux exemples présentés ici sont également accessibles via la Bibliothèques d'Applications intégrée au logiciel COMSOL Multiphysics® et disponible à partir du menu Fichier.
This model demonstrates a technique for partitioning a mesh based upon the element type. By first meshing with a boundary layer and then partitioning and creating a new mesh, it is possible to avoid modeling the interior volume of inductively heated parts, where the skin depth is small ... En savoir plus
A spherical hydrophone consisting of a PZT ceramic, a coating material, and a cable is modeled in 2D axisymmetry. The Receiving Voltage Sensitivity (RVS) is computed for an incident plane wave and compared to an analytical solution from the reference for an ideal spherical hydrophone. ... En savoir plus
This model demonstrates the motion of a bicycle with a hands-free rider when given an initial forward velocity and perturbed with a lean about the forward axis. This is implemented through the Multibody Dynamics module in COMSOL. The wheels of the bicycle have been modelled assuming ... En savoir plus
This application uses the shrinking core model to study the reduction of iron ore pellets. A 1D model of a packed bed containing iron ore pellets is modeled. The bed filling pellets initially consists of solid phase FeO. The pellets are reduced by CO, and the solid core shrinks leaving a ... En savoir plus
An acoustic point source emits a pressure wave in water that travels toward a piece of glass. Cracks are formed and propagate due to high tensile stresses developed in the glass. A fully coupled acoustic-structure interaction problem including phase field damage in solids is solved in ... En savoir plus
Topology optimization is associated with extreme design freedom which can yield extreme performance. The designs can be easier to manufacture by using milling constraints, at some cost to the performance. This example considers the case of a torsion sphere which is known to feature a ... En savoir plus
This model demonstrates 2D topology optimization for the problem of minimum mass subject to a compliance constraint and a stress constraint. The stress constraint is implemented with a P-norm global aggregation function. The stress input to this is interpolated differently than the Young ... En savoir plus
The purpose of this model is to demonstrate pure rolling of a rigid wheel when given an initial forward velocity together with a prescribed lean about this direction. It is assumed that the the rolling motion of the wheel is not affected by contact such that all three components of the ... En savoir plus
This example illustrates the modeling of a tensegrity table. The table is made of two rigid bodies connected through a central wire and four outer wires. Two cases are analyzed. In the first case, the top of the table is loaded with vertically downward acting load of varying magnitude. ... En savoir plus
This tutorial studies the propagation of sound in the presence of a porous absorber in the time domain. It demonstrates how to model a porous absorber using the local and extended reacting approximations and compares the two approaches for absorbers of various thickness. The dissipative ... En savoir plus
