Biconical Antenna

Application ID: 12075

A Biconical antenna is a type of wideband antenna with omni-directional radiation pattern in the H-plane similar to a dipole antenna. A coaxial feed is connected to the radiators using two 90 degree bent arms.

The model shows that the biconical antenna works well in applications requiring an omnidirectional radiation pattern and wide bandwidth.
